DEWALT DRYWALL SANDER (Type 1)
SKU Produs: DWE7800 /Type: 1
| Pozitie | Cod piesa | Piese utilizate | Nume piesa | Pret | Cantitate/Adauga in cos |
|---|---|---|---|---|---|
| 1 | N793310 | 1 | HOUSING SA | 106,98 Lei | |
| 2 | N793345 | 1 | HOUSING SA | 34,05 Lei | |
| 3 | 645825-00 | 1 | TUBE SUPPORT | 58,17 Lei | |
| 6 | N734932 | 1 | CONTROL MODULE SA | 106,98 Lei | |
| 7 | N734932 | 1 | CONTROL MODULE SA | 106,98 Lei | |
| 8 | 877755 | 4 | SPRING | 3,78 Lei | |
| 10 | 877774 | 1 | TUBE GUIDE | 43,16 Lei | |
| 13 | NA655846 | 3 | PIN | 16,49 Lei | |
| 14 | N928278 | 1 | STUD | 4,7 Lei | |
| 17 | NA177367 | 2 | SCREW | 3,78 Lei | |
| 19 | 884843 | 2 | CLAMP | 21,11 Lei | |
| 20 | 882187 | 2 | SCREW | 4,57 Lei | |
| 21 | 879772 | 1 | BELLOWS | 10,5 Lei | |
| 25 | 861434 | 2 | CORD CLAMP | 3,78 Lei | |
| 26 | 330019-11 | 4 | SCREW PLSTC THD FORM M4.55X13 T20 | 4,57 Lei | |
| 27 | NA021871 | 1 | GEARCASE SA | 96,56 Lei | |
| 28 | 605040-20 | 1 | Ball Brg | 17,02 Lei | |
| 29 | 859382 | 1 | RING | 6,09 Lei | |
| 30 | 330004-00 | 1 | BEARING | 11,45 Lei | |
| 31 | NA021873 | 1 | SPINDLE | 130,35 Lei | |
| 32 | NA021873 | 1 | SPINDLE | 130,35 Lei | |
| 33 | 023813-00 | 1 | WASHER FIBRE | 3,78 Lei | |
| 34 | 176655-00 | 1 | GASKET | 4,57 Lei | |
| 35 | NA021874 | 1 | GEAR AND PINION | 145,09 Lei | |
| 36 | NA021874 | 1 | GEAR AND PINION | 145,09 Lei | |
| 37 | 143079-00 | 1 | BEARING, THRUST | 5,21 Lei | |
| 38 | 176732-00 | 3 | WASHER, THRUST | 4,57 Lei | |
| 39 | N655784 | 1 | FIELD CASE | 25,54 Lei | |
| 40 | NA170923 | 1 | FIELD SA | 240,38 Lei | |
| 41 | NA174057 | 1 | ARMATURE AND FAN | 213,19 Lei | |
| 42 | N440278 | 1 | BRUSH HOLDER | 19,95 Lei | |
| 43 | N440279 | 1 | BRUSH HOLDER | 19,95 Lei | |
| 44 | NA219005 | 1 | GEARCASE COVER SA | 66,15 Lei | |
| 45 | 949638-02 | 2 | SMALL RUBBER | 4,57 Lei | |
| 46 | 176951-00 | 2 | SCREW | 4,57 Lei | |
| 47 | 176846-04 | 2 | BRUSH 120V | 5,21 Lei | |
| 48 | 330019-14 | 1 | SCREW, PLASTIC THREAD FORM M4X25 T20 | 4,57 Lei | |
| 49 | 330019-16 | 2 | SCREW, PLASTIC THD FORM, M4*38 T20 | 4,57 Lei | |
| 50 | 089210-00 | 1 | RING, RETAINER, ROUND | 6,23 Lei | |
| 51 | 176811-00 | 1 | FAN BAFFLE | 7,37 Lei | |
| 52 | NA086870 | 1 | VACUUM TUBE SA | 667,9 Lei | |
| 53 | N725018 | 1 | SUPPORT | 80,04 Lei | |
| 54 | N690875 | 1 | SPINDLE | 41,93 Lei | |
| 54 | NA021877 | 1 | SPINDLE SA | 79,8 Lei | |
| 55 | 684179 | 1 | SNAP RING | 4,57 Lei | |
| 56 | 605040-72 | 2 | BEARING | 17,02 Lei | |
| 57 | N118088 | 3 | SCREW , SHOULDER M3X0,5 | 4,57 Lei | |
| 58 | N753929 | 1 | SLIDER | 7,37 Lei | |
| 59 | N768963 | 1 | TRIGGER | 6,23 Lei | |
| 60 | 330016-25 | 1 | WASHER, PLAIN 8.25X4.25X0.607 | 4,57 Lei | |
| 61 | 593387-00 | 1 | SCREW | 4,57 Lei | |
| 62 | N327459 | 1 | CPX CDO 80-01 SWITCH | 19,95 Lei | |
| 63 | N760899 | 1 | SPRING | 17,02 Lei | |
| 64 | NA028367 | 1 | HOUSING | 80,04 Lei | |
| 65 | A01929 | 1 | HOSE SA | 139,97 Lei | |
| 66 | 659373-00 | 1 | CASING | 150,05 Lei | |
| 67 | 389007-00 | 1 | DBL-END SCREW | 21,85 Lei | |
| 68 | 389031-00 | 1 | NUT | 4,57 Lei | |
| 69 | 659372-00 | 1 | DRIVE SHAFT | 66,15 Lei | |
| 70 | 146929-00 | 1 | SCREW | 4,57 Lei | |
| 71 | 697861 | 3 | TERMINAL | 4,57 Lei | |
| 72 | 683784 | 2 | TERMINAL | 3,78 Lei | |
| 73 | N779415 | 1 | CORDSET | 252,58 Lei | |
| 74 | N918736 | 1 | CORD PROTECTOR | 5,21 Lei | |
| 75 | 802429 | 1 | WASHER LOCK | 4,57 Lei | |
| 76 | 913139 | 1 | CLIP | 15,12 Lei | |
| 77 | N792249 | 1 | INSULATOR | 19,95 Lei | |
| 78 | N835652 | 1 | PLASTIC INSERT | 6,23 Lei | |
| 79 | 882703 | 6 | SCREW | 4,57 Lei | |
| 80 | N859471 | 1 | PAD | 70,39 Lei | |
| 81 | 882685 | 1 | DISC | 28,14 Lei | |
| 82 | N862100 | 2 | FOAM | 96,56 Lei | |
| 83 | 877738 | 1 | WASHER | 11,45 Lei | |
| 84 | N862773 | 1 | NUT | 13,85 Lei | |
| 85 | 330019-45 | 15 | SCREW | 4,57 Lei | |
| 86 | N736672 | 1 | BRUSH | 88,55 Lei | |
| 88 | N855826 | 1 | PAD SA | 200,99 Lei | |
| 100 | N786864 | 1 | RATING LABEL | 19,95 Lei | |
| 101 | N168439 | 1 | LABEL | 4,57 Lei | |
| 800 | N017298 | 1 | GREASE | 213,19 Lei |
