DEWALT ANGLE GRINDER (Type 1)
SKU Produs: DWE46107 /Type: 1
| Pozitie | Cod piesa | Piese utilizate | Nume piesa | Pret | Cantitate/Adauga in cos |
|---|---|---|---|---|---|
| 1 | NA146577 | 1 | GEARCASE SA | 96,56 Lei | |
| 2 | N442428 | 1 | ARMATURE 230V | 177,2 Lei | |
| 2 | N442432 | 1 | RATING PLATE | 4,57 Lei | |
| 2 | NA146600 | 1 | ARMATURE SA | 361,33 Lei | |
| 3 | N423537 | 1 | PINION 38T/10T LONG | 25,54 Lei | |
| 4 | N372039 | 1 | NUT M7 | 4,57 Lei | |
| 5 | NA148917 | 1 | SPINDLE SA | 181,55 Lei | |
| 7 | N413349 | 2 | BRUSHBOX SA | 19,95 Lei | |
| 8 | N442427 | 1 | BRUSH PAIR 230V | 24,9 Lei | |
| 8 | NA121924 | 1 | BRUSH PAIR | 37,73 Lei | |
| 10 | N484918 | 1 | SWITCH | 21,85 Lei | |
| 12 | N093410 | 1 | SPRING | 4,57 Lei | |
| 13 | N097844 | 1 | BUTTON | 4,57 Lei | |
| 14 | N387328 | 1 | CORDSET (EURO) | 80,04 Lei | |
| 14 | N387331 | 1 | CORDSET | 52,22 Lei | |
| 15 | N918736 | 1 | CORD PROTECTOR | 5,21 Lei | |
| 16 | 619328-00 | 1 | CORD CLAMP | 4,57 Lei | |
| 17 | 330065-06 | 1 | SCREW PLSTC THD FROM M4X12 T20 | 4,57 Lei | |
| 18 | N419604 | 1 | HOUSING SA | 21,85 Lei | |
| 19 | N563707 | 1 | DUST PORT | 10,29 Lei | |
| 20 | N400902 | 1 | END CAP | 8,64 Lei | |
| 21 | N371839 | 4 | SCREW, PLSTC THD FORM, M4X22 T20 | 4,57 Lei | |
| 22 | 330045-06 | 5 | SCREW, METAL THD FRM,M4X16 T20 | 4,57 Lei | |
| 23 | N130031 | 1 | SCREW | 4,57 Lei | |
| 26 | N389438 | 3 | SCREW PLSTC THD FORM | 4,57 Lei | |
| 27 | 330065-09 | 1 | SCREW PLSTC THD FORM M4X25 T20 | 4,57 Lei | |
| 28 | 593478-00 | 4 | SCREW OT M3X8 | 4,57 Lei | |
| 30 | N408538 | 1 | SA RC, NV SAG | 17,02 Lei | |
| 31 | 634599-00 | 1 | TERMINAL | 4,57 Lei | |
| 32 | N301299 | 1 | SA NO VOLT MODULE | 86,4 Lei | |
| 32 | NA152190 | 1 | CONTROL MODULE SA | 157,92 Lei | |
| 35 | 631028-00 | 1 | LEAD SA D28136 | 7,37 Lei | |
| 36 | N654478 | 1 | Inner Flange | 25,54 Lei | |
| 37 | N666474 | 1 | OUTER FLANGE | 30,87 Lei | |
| 38 | N542715 | 1 | WASHER SPRING | 6,23 Lei | |
| 40 | N403730 | 1 | IDENTITY LABEL | 4,57 Lei | |
| 41 | N819745 | 1 | RATING PLATE | 4,57 Lei | |
| 50 | N420261 | 1 | O RING | 4,57 Lei | |
| 62 | N399419 | 1 | BAFFLE | 7,37 Lei | |
| 63 | 949638-02 | 2 | SMALL RUBBER | 4,57 Lei | |
| 64 | NA121487 | 1 | FIELD | 240,38 Lei | |
| 65 | N390640 | 1 | FIELDCASE COMPACT SLIDER CAD FREE | 34,05 Lei | |
| 71 | N107295 | 1 | HEX KEY 6 MM | 6,23 Lei | |
| 72 | N382311 | 1 | SIDE HANDLE | 52,22 Lei | |
| 85 | 444793-00 | 1 | RETAINING RING | 4,57 Lei | |
| 86 | N409481 | 1 | Gear | 57,81 Lei | |
| 86 | N887607 | 1 | Gear | 80,04 Lei | |
| 87 | N163702 | 1 | SPINDLE M14 | 25,54 Lei | |
| 88 | 605040-24 | 1 | BEARING | 13,85 Lei | |
| 89 | N400478 | 1 | SLINGER | 4,57 Lei | |
| 90 | N481950 | 1 | RETAINER RING | 4,57 Lei | |
| 91 | N307625 | 1 | O RING 1.5X40 | 4,57 Lei | |
| 92 | N441765 | 1 | GCC MACH | 30,87 Lei | |
| 95 | 641823-00 | 1 | BOOT, RUBBER | 4,57 Lei | |
| 96 | N130916 | 1 | BEARING | 10,29 Lei | |
| 97 | N324400 | 1 | SLINGER THOR | 4,57 Lei | |
| 99 | N273780 | 2 | SPRING, THOR BRUSH BOX | 4,57 Lei | |
| 99 | N274440 | 2 | RATING LABEL | 4,57 Lei | |
| 101 | N645894 | 1 | DUST PORT | 25,54 Lei | |
| 102 | N651615 | 1 | COVER | 10,29 Lei | |
| 103 | N645891 | 1 | CLAMSHELL HALF | 52,22 Lei | |
| 104 | N645890 | 1 | CLAMSHELL HALF | 41,93 Lei | |
| 105 | N646433 | 1 | SPRING | 5,21 Lei | |
| 106 | N645896 | 1 | PIN | 15,12 Lei | |
| 107 | N743974 | 1 | WASHER | 4,57 Lei | |
| 108 | 098197-10 | 1 | WASHER LOCK | 4,57 Lei | |
| 109 | 153778-01 | 1 | Mach screw | 4,57 Lei | |
| 110 | N646437 | 1 | BACKPLATE | 19,95 Lei | |
| 111 | N646443 | 1 | STRAP | 34,05 Lei | |
| 112 | 631609-03 | 1 | SCREW | 4,57 Lei | |
| 113 | 90611830 | 10 | SCREW | 4,57 Lei | |
| 114 | N530541 | 2 | SCREW | 4,57 Lei | |
| 115 | 330019-66 | 3 | SCREW | 4,57 Lei | |
| 116 | N760650 | 8 | PLASTIC SCREW | 4,57 Lei | |
| 117 | N659081 | 1 | CLAMSHELL HALF | 25,54 Lei | |
| 118 | N645892 | 1 | CLAMSHELL HALF | 30,87 Lei | |
| 119 | N116219 | 2 | NUT | 4,57 Lei | |
| 120 | N647700 | 1 | WINDOW | 7,37 Lei | |
| 121 | 478455-00 | 2 | SCREW | 4,57 Lei | |
| 122 | N646434 | 1 | SPRING | 4,57 Lei | |
| 123 | N645899 | 1 | LATCH BUTTON | 5,21 Lei | |
| 124 | N646432 | 1 | PIN | 4,57 Lei | |
| 125 | N770509 | 1 | SPRING | 4,57 Lei | |
| 126 | N645897 | 1 | LOCK HOOK | 34,05 Lei | |
| 127 | N646427 | 1 | STRAP | 30,87 Lei | |
| 128 | N646444 | 1 | LATCH | 41,93 Lei | |
| 129 | N646430 | 1 | BRACKET | 7,37 Lei | |
| 130 | N646428 | 1 | KNOB | 5,21 Lei | |
| 131 | N645902 | 1 | SHOE | 34,05 Lei | |
| 131 | N645905 | 1 | RATING PLATE | 4,5 Lei | |
| 133 | N703486 | 4 | WHEEL | 5,21 Lei | |
| 134 | N774538 | 4 | WASHER | 4,57 Lei | |
| 135 | N703485 | 2 | AXLE | 7,37 Lei | |
| 136 | N654478 | 1 | Inner Flange | 25,54 Lei | |
| 137 | N666474 | 1 | OUTER FLANGE | 30,87 Lei | |
| 138 | N665586 | 1 | Inner Flange | 25,54 Lei | |
| 139 | N665610 | 1 | OUTER FLANGE | 25,54 Lei | |
| 141 | N456231 | 1 | LABEL | 4,57 Lei | |
| 142 | 388405-00 | 3 | SCREW | 4,57 Lei | |
| 201 | N401958 | 1 | DEFLECTOR | 5,21 Lei | |
| 202 | N453031 | 1 | RET RING w FINGERS | 4,57 Lei | |
| 203 | N175104 | 1 | BEARING BALL | 13,85 Lei | |
| 204 | N119639 | 1 | O RING ,RUBBER | 4,57 Lei | |
| 205 | N278899 | 1 | SPINDLE LOCK BUTTON | 4,57 Lei | |
| 206 | N263579 | 1 | THOR SPINDLE LOCK SPRING | 4,57 Lei | |
| 207 | N481683 | 1 | LOCK PIN | 7,37 Lei | |
| 208 | N263699 | 1 | THOR SPINDLE LOCK O-RING | 4,57 Lei | |
| 800 | 583534-00 | 1 | RHEOLUBE 380-G1 | 1087,42 Lei |
