DEWALT SMALL ANGLE GRINDER (Type 1)
SKU Produs: DWE46106 /Type: 1
| Pozitie | Cod piesa | Piese utilizate | Nume piesa | Pret | Cantitate/Adauga in cos |
|---|---|---|---|---|---|
| 1 | N389433 | 1 | ARMATURE 230V | 190,3 Lei | |
| 1 | NA160492 | 1 | ARMATURE SA | 331,47 Lei | |
| 4 | N115132 | 1 | HOUSING | 17,02 Lei | |
| 6 | N442171 | 1 | SWITCH | 90,6 Lei | |
| 8 | N183725 | 1 | BRUSH PAIR | 40,9 Lei | |
| 8 | NA160502 | 1 | BRUSH PAIR | 41,93 Lei | |
| 11 | N442344 | 1 | CAPACITOR SA | 17,02 Lei | |
| 12 | N017839 | 1 | SCREW | 4,57 Lei | |
| 13 | 562097-00 | 1 | Screw For Brush Holder Assy.(4.2 x 13) | 4,57 Lei | |
| 14 | 619328-00 | 1 | CORD CLAMP | 4,57 Lei | |
| 15 | N918736 | 1 | CORD PROTECTOR | 5,21 Lei | |
| 17 | 330065-31 | 4 | SCREW | 4,57 Lei | |
| 18 | N133090 | 1 | CORDSET (EURO) | 37,73 Lei | |
| 19 | N097844 | 1 | BUTTON | 4,57 Lei | |
| 20 | N654478 | 1 | Inner Flange | 25,54 Lei | |
| 21 | N666474 | 1 | OUTER FLANGE | 30,87 Lei | |
| 23 | N130031 | 1 | SCREW | 4,57 Lei | |
| 25 | N135116 | 1 | WASHER SPRING | 6,23 Lei | |
| 26 | 593478-00 | 2 | SCREW OT M3X8 | 4,57 Lei | |
| 28 | N149175 | 1 | BRAND LABEL | 4,57 Lei | |
| 29 | N819741 | 1 | RATING PLATE | 4,57 Lei | |
| 31 | 604484-00 | 1 | NUT M6 | 4,57 Lei | |
| 32 | N153125 | 1 | PINION | 17,02 Lei | |
| 33 | N175104 | 1 | BEARING BALL | 13,85 Lei | |
| 34 | N132042 | 1 | BAFFLE | 6,23 Lei | |
| 34 | N132103 | 1 | HOUSING UPPER | 57,81 Lei | |
| 36 | N101228 | 1 | WASHER | 4,57 Lei | |
| 37 | N130916 | 1 | BEARING | 10,29 Lei | |
| 38 | 641823-00 | 1 | BOOT, RUBBER | 4,57 Lei | |
| 39 | N213812 | 1 | WASHER | 4,57 Lei | |
| 41 | N115131 | 1 | FIELDCASE | 34,05 Lei | |
| 42 | N232482 | 1 | FIELD 230V | 123,6 Lei | |
| 43 | N132864 | 1 | BAFFLE | 5,21 Lei | |
| 44 | 330065-25 | 4 | SCREW PLSTC THD FORM M3X9 T10 | 4,57 Lei | |
| 45 | N097702 | 2 | BRUSH BOX | 7,37 Lei | |
| 46 | N097703 | 2 | SPRING | 4,57 Lei | |
| 47 | N117648 | 1 | LINK | 5,21 Lei | |
| 48 | N093410 | 1 | SPRING | 4,57 Lei | |
| 53 | N153126 | 1 | Gear | 25,54 Lei | |
| 54 | 605040-24 | 1 | BEARING | 13,85 Lei | |
| 55 | N094024 | 1 | O RING | 4,57 Lei | |
| 56 | N118088 | 3 | SCREW , SHOULDER M3X0,5 | 4,57 Lei | |
| 57 | N447838 | 1 | WASHER BEARING BLOCK | 4,57 Lei | |
| 58 | N092954 | 1 | SPRING COMPRESSION | 4,57 Lei | |
| 59 | N126708 | 1 | PLUG, RUBBER | 4,57 Lei | |
| 60 | 444793-00 | 1 | RETAINING RING | 4,57 Lei | |
| 61 | N126105 | 1 | BUTTON | 4,57 Lei | |
| 62 | N122904 | 4 | SCREW M3 5X0,6 | 4,57 Lei | |
| 63 | N116180 | 1 | GEARCASE COVER | 5,21 Lei | |
| 64 | N119639 | 1 | O RING ,RUBBER | 4,57 Lei | |
| 65 | N094012 | 1 | O RING | 4,57 Lei | |
| 66 | N114592 | 1 | PIN SPINDLE LOCK | 5,21 Lei | |
| 67 | N181767 | 1 | SPINDLE LOCK | 15,12 Lei | |
| 68 | N232479 | 1 | GEARCASE SA | 141,6 Lei | |
| 71 | N110057 | 1 | SPINDLE M14 | 25,54 Lei | |
| 72 | 605040-24 | 1 | BEARING | 13,85 Lei | |
| 73 | N095815 | 1 | SLEEVE | 5,21 Lei | |
| 74 | 638229-00 | 1 | SLINGER | 4,57 Lei | |
| 80 | 562211-00 | 1 | Handle Side(945597-00) DW803/801 | 17,02 Lei | |
| 81 | N107295 | 1 | HEX KEY 6 MM | 6,23 Lei | |
| 101 | N645894 | 1 | DUST PORT | 25,54 Lei | |
| 102 | N651615 | 1 | COVER | 10,29 Lei | |
| 103 | N645891 | 1 | CLAMSHELL HALF | 52,22 Lei | |
| 104 | N645890 | 1 | CLAMSHELL HALF | 41,93 Lei | |
| 105 | N646433 | 1 | SPRING | 5,21 Lei | |
| 106 | N645896 | 1 | PIN | 15,12 Lei | |
| 107 | N743974 | 1 | WASHER | 4,57 Lei | |
| 108 | 098197-10 | 1 | WASHER LOCK | 4,57 Lei | |
| 109 | 153778-01 | 1 | Mach screw | 4,57 Lei | |
| 110 | N646437 | 1 | BACKPLATE | 19,95 Lei | |
| 111 | N646443 | 1 | STRAP | 34,05 Lei | |
| 112 | 631609-03 | 1 | SCREW | 4,57 Lei | |
| 113 | 90611830 | 10 | SCREW | 4,57 Lei | |
| 114 | N530541 | 2 | SCREW | 4,57 Lei | |
| 115 | 330019-66 | 3 | SCREW | 4,57 Lei | |
| 116 | N760650 | 8 | PLASTIC SCREW | 4,57 Lei | |
| 117 | N659081 | 1 | CLAMSHELL HALF | 25,54 Lei | |
| 118 | N645892 | 1 | CLAMSHELL HALF | 30,87 Lei | |
| 119 | N116219 | 2 | NUT | 4,57 Lei | |
| 120 | N647700 | 1 | WINDOW | 7,37 Lei | |
| 121 | 478455-00 | 2 | SCREW | 4,57 Lei | |
| 122 | N646434 | 1 | SPRING | 4,57 Lei | |
| 123 | N645899 | 1 | LATCH BUTTON | 5,21 Lei | |
| 124 | N646432 | 1 | PIN | 4,57 Lei | |
| 125 | N770509 | 1 | SPRING | 4,57 Lei | |
| 126 | N645897 | 1 | LOCK HOOK | 34,05 Lei | |
| 127 | N646427 | 1 | STRAP | 30,87 Lei | |
| 128 | N646444 | 1 | LATCH | 41,93 Lei | |
| 129 | N646430 | 1 | BRACKET | 7,37 Lei | |
| 130 | N646428 | 1 | KNOB | 5,21 Lei | |
| 131 | N645902 | 1 | SHOE | 34,05 Lei | |
| 131 | N645905 | 1 | RATING PLATE | 4,5 Lei | |
| 133 | N703486 | 4 | WHEEL | 5,21 Lei | |
| 134 | N774538 | 4 | WASHER | 4,57 Lei | |
| 135 | N703485 | 2 | AXLE | 7,37 Lei | |
| 136 | N654478 | 1 | Inner Flange | 25,54 Lei | |
| 137 | N666474 | 1 | OUTER FLANGE | 30,87 Lei | |
| 138 | N665586 | 1 | Inner Flange | 25,54 Lei | |
| 139 | N665610 | 1 | OUTER FLANGE | 25,54 Lei | |
| 141 | N456231 | 1 | LABEL | 4,57 Lei | |
| 142 | 388405-00 | 3 | SCREW | 4,57 Lei | |
| 800 | 583534-00 | 1 | RHEOLUBE 380-G1 | 1087,42 Lei |
