DEWALT TABLE SAW (Type 6)
SKU Produs: DW711 /Type: 6
| Pozitie | Cod piesa | Piese utilizate | Nume piesa | Pret | Cantitate/Adauga in cos |
|---|---|---|---|---|---|
| 1 | 869313-00 | 1 | BASE DW777, SERVICE | 451,79 Lei | |
| 2 | N717627 | 1 | TABLE DWS777 IEC (SERVICE) | 375,31 Lei | |
| 3 | 861057-01 | 1 | Inner Flange | 41,93 Lei | |
| 4 | 861056-00 | 1 | OUTER FLANGE TGS273 | 30,87 Lei | |
| 5 | 949886-21 | 1 | SOCKET HEAD SCREW SX | 30,87 Lei | |
| 6 | 864693-04 | 1 | SA SWINGING PROTECTION DW711 | 200,99 Lei | |
| 7 | 863039-02 | 1 | MOZZO PROT OSCILL.DW711 | 7,37 Lei | |
| 8 | 330045-49 | 2 | SCREW | 4,57 Lei | |
| 9 | 930085-00 | 2 | SCREW TSPPH 2,9X9,5 | 4,57 Lei | |
| 10 | 860092-00 | 1 | NUT,ELAST.STOP M.6 UNI 7474 | 4,57 Lei | |
| 11 | 860075-01 | 1 | WASHER,FLAT SPEC.5.5X20X1.5 | 4,57 Lei | |
| 12 | 949761-01 | 2 | WASHER FOR SCREW | 5,21 Lei | |
| 13 | 861918-04 | 1 | FIXED PROTECTION DW711 | 37,73 Lei | |
| 16 | 943025-00 | 1 | PLATE | 4,57 Lei | |
| 17 | N162669 | 1 | BLADE GUARD DW711/DW743N | 41,93 Lei | |
| 18 | 860092-00 | 1 | NUT,ELAST.STOP M.6 UNI 7474 | 4,57 Lei | |
| 19 | N059524 | 1 | BUSHING | 13,85 Lei | |
| 20 | 860093-05 | 1 | SCREW,SOCKET M.6X20 UNI 5931 | 4,57 Lei | |
| 20 | 860093-06 | 1 | SCREW,SOCKET M.6X25 UNI 5931 | 4,57 Lei | |
| 21 | N060228 | 1 | KNOB | 181,55 Lei | |
| 22 | 861464-00 | 1 | KNOB | 8,64 Lei | |
| 23 | N056486 | 1 | SPRING TORSION DW711 | 5,21 Lei | |
| 24 | 861953-00 | 1 | CLAMP LEVER PUSH DW711 | 25,54 Lei | |
| 25 | 863610-00 | 1 | HEAD BLOCKING PLATE DW250-DW25 | 21,85 Lei | |
| 26 | 861919-01 | 1 | RIVING KNIFE DW711 | 52,22 Lei | |
| 27 | 949886-16 | 1 | SOCKET HD.SCREW M8X16 | 4,57 Lei | |
| 28 | 860074-03 | 1 | WASHER,SPRING CON.D8.2X18X1 | 4,57 Lei | |
| 29 | 939072-00 | 1 | WRENCH | 37,73 Lei | |
| 30 | 860093-00 | 1 | SCREW,SOCKET M.8X30 UNI 5931 | 4,57 Lei | |
| 31 | N060327 | 1 | SWITCH | 88,55 Lei | |
| 32 | 861692-00 | 1 | CLAMP SOM 2124149 | 8,8 Lei | |
| 33 | 949889-02 | 2 | SCREW | 4,57 Lei | |
| 34 | 868320-00 | 1 | SWITCH COVER | 17,02 Lei | |
| 35 | N174180 | 1 | SA TOP GUARD DW711 T.7 (SERVICE) | 157,92 Lei | |
| 36 | 868688-01 | 1 | YELLOW TABLE BASE INSERT | 15,12 Lei | |
| 37 | 949705-01 | 2 | WASHER | 4,57 Lei | |
| 38 | 860085-09 | 1 | SCREW,HEX M.6X20 UNI5739 BLCK | 4,57 Lei | |
| 39 | 860083-12 | 2 | NUT M6 | 4,57 Lei | |
| 40 | 861840-03 | 1 | LEVER SC | 19,95 Lei | |
| 41 | 860092-07 | 2 | NUT,LOCKING M12X1,25 | 4,57 Lei | |
| 42 | 868680-00 | 1 | BEVEL CLAMP DW777 | 13,85 Lei | |
| 43 | 861913-02 | 1 | HEAD SUPPORT DW711 | 213,19 Lei | |
| 44 | 863262-00 | 1 | SCREW,FOR PROTECTION BAR -DW25 | 13,85 Lei | |
| 45 | 863046-00 | 1 | PIN SA | 15,12 Lei | |
| 46 | 860093-07 | 1 | SCREW,SOCKET M.8X20 UNI 5931 | 4,57 Lei | |
| 47 | 860083-04 | 1 | NUT,HEX THICK M.8 UNI 5587 | 4,57 Lei | |
| 48 | 863047-00 | 1 | KNOB | 15,12 Lei | |
| 50 | 863048-00 | 1 | BUSH | 13,85 Lei | |
| 51 | 949722-18 | 1 | SPRING | 4,57 Lei | |
| 52 | 862075-01 | 1 | RIV.KNIFE SPACER SUPPORT 711 | 13,85 Lei | |
| 54 | N062687 | 1 | LABEL WARNING DW711 T.6 | 12,71 Lei | |
| 55 | 869374-00 | 1 | SA FRONT GUARD+BUSHING DW711 T.6 | 145,09 Lei | |
| 56 | 863599-02 | 1 | DISTANCIAL | 7,37 Lei | |
| 57 | 861920-00 | 1 | FRONT BOX DW711,BLACK | 17,02 Lei | |
| 58 | 949761-02 | 1 | SHIM | 4,57 Lei | |
| 59 | 949759-01 | 1 | LOCK NUT FOR PIVOT PIN DW250-D | 25,54 Lei | |
| 60 | 860085-07 | 1 | SCREW | 4,57 Lei | |
| 61 | 930076-00 | 2 | SELF TAPPING SCREW 4,2X16 | 4,57 Lei | |
| 62 | 863606-00 | 1 | LEFT TORSIONAL SPRING DW250-DW | 37,73 Lei | |
| 63 | 863590-00 | 1 | RIGHT TORSIONAL SPRING DW250-D | 37,73 Lei | |
| 64 | 863611-00 | 1 | HEAD SHIM DW250-DW252 | 15,12 Lei | |
| 65 | 863602-00 | 1 | HEAD BLOCKING PIN | 15,12 Lei | |
| 67 | 863604-01 | 2 | HEAD BLOCKING SPRING DW250-DW2 | 4,57 Lei | |
| 68 | 863607-00 | 1 | JOINT AXLE DW250 | 57,81 Lei | |
| 69 | 860074-01 | 1 | WASHER,SPRING CON.D5.2X12X0.8 | 4,57 Lei | |
| 70 | 868520-00 | 1 | CORD PROTECTOR | 5,21 Lei | |
| 71 | 860094-02 | 2 | SCREW,PAN PH/TT M.4X8 UNI8112 | 4,57 Lei | |
| 72 | 868478-00 | 1 | EXTRACTION KIT, DW711 | 41,93 Lei | |
| 73 | 939625-00 | 1 | WASHER | 4,57 Lei | |
| 74 | 860084-21 | 1 | SELF TAPPING SCREW 4 | 4,57 Lei | |
| 75 | 865410-00 | 1 | PLATE NUT | 4,57 Lei | |
| 76 | 868478-00 | 1 | EXTRACTION KIT, DW711 | 41,93 Lei | |
| 77 | N056428 | 1 | FLAP,GUARD DW711 | 19,5 Lei | |
| 78 | N056427 | 1 | FLAP,GUARD DW711 | 21,3 Lei | |
| 79 | 863026-00 | 1 | GASKET | 4,57 Lei | |
| 80 | 863604-01 | 1 | HEAD BLOCKING SPRING DW250-DW2 | 4,57 Lei | |
| 81 | 944650-00 | 1 | CLAMP,WIRE ZINC PLATED | 4,57 Lei | |
| 82 | 863573-00 | 1 | CABLE INLET RING DW250-DW252 | 7,37 Lei | |
| 83 | 862429-05 | 1 | HANDLE DW711 | 106,98 Lei | |
| 84 | 863613-01 | 1 | UNLOCKING HEAD BAR DW711 | 37,73 Lei | |
| 85 | 402803-02 | 1 | TABLE PROTECTION DW711 | 30,87 Lei | |
| 87 | 860074-00 | 2 | WASHER,SPRING CON.D4.2X10X0.6 | 4,57 Lei | |
| 89 | 330045-26 | 1 | SCREW | 6,23 Lei | |
| 91 | N783370 | 1 | FENCE | 195,02 Lei | |
| 93 | 860084-09 | 1 | SCREW,PAN PHAB 4.2X22 UNI6954 | 4,57 Lei | |
| 94 | 863025-00 | 1 | RUBBER FOR SCREW-DW250-252 | 7,37 Lei | |
| 95 | 860075-00 | 1 | WASHER,FLAT SPEC. 6.4X16X1.5 | 4,57 Lei | |
| 98 | 949772-23 | 1 | CAPACITOR | 70,39 Lei | |
| 99 | 860094-03 | 1 | SCREW,PAN PH/TT M.4X10UNI8112 | 4,57 Lei | |
| 101 | 860084-22 | 1 | SCREW TCBPH5,5X25 6954ZP | 4,57 Lei | |
| 102 | 868677-00 | 1 | SCALE | 52,22 Lei | |
| 103 | 869189-02 | 1 | S/A UPPER TABLE DW711 | 307,21 Lei | |
| 104 | 402801-00 | 1 | BRACKET | 41,93 Lei | |
| 106 | 949886-16 | 1 | SOCKET HD.SCREW M8X16 | 4,57 Lei | |
| 107 | 391358-01 | 1 | HOLDER | 7,37 Lei | |
| 108 | 720688-02 | 1 | SCREW (080914604) | 4,57 Lei | |
| 109 | 868707-01 | 1 | SPACER FOR LOCKING SYSTEM DW777 | 4,57 Lei | |
| 110 | 860092-03 | 1 | NUT M5 | 4,57 Lei | |
| 111 | 869195-00 | 1 | KNOB | 10,29 Lei | |
| 112 | 868777-00 | 4 | FOOT | 4,57 Lei | |
| 115 | 861464-00 | 1 | KNOB | 8,64 Lei | |
| 116 | 860073-05 | 2 | WASHER,FLAT 13X24 UNI 6592 | 4,57 Lei | |
| 117 | 860205-08 | 2 | SCREW,PAN PH/TT M.4X14 UNI8112 | 4,57 Lei | |
| 119 | 868943-02 | 1 | LOCKING DEVICE | 37,73 Lei | |
| 120 | 861748-00 | 1 | SUPPORT | 4,57 Lei | |
| 121 | 861982-00 | 1 | SA SLIDING FENCE | 307,21 Lei | |
| 122 | 868778-00 | 1 | SPRING | 4,57 Lei | |
| 123 | 402800-01 | 1 | TABLE SUPPORT (FEM.) 711 | 80,04 Lei | |
| 125 | 868313-10 | 1 | CABLE+PLUG, DW710 | 70,39 Lei | |
| 126 | 861422-02 | 1 | PARALLEL FENCE L.150 | 41,93 Lei | |
| 127 | 861453-00 | 1 | SPACER | 17,02 Lei | |
| 128 | 949886-11 | 2 | SCREW | 4,57 Lei | |
| 129 | 861421-01 | 1 | FENCE SUPPORT-DW711 | 41,93 Lei | |
| 130 | 862180-08 | 1 | SUPPORT BRACKET DW711 A3 | 264,01 Lei | |
| 131 | 861452-00 | 1 | KNOB | 12,71 Lei | |
| 133 | 861423-00 | 2 | END CAP | 8,64 Lei | |
| 134 | 860073-14 | 2 | WASHER,FLAT 6.6X18X2 UNI6593 | 4,57 Lei | |
| 136 | 860445-00 | 1 | COVER,FAN MOTOR DW 250 | 25,54 Lei | |
| 137 | 945841-00 | 1 | FAN | 17,02 Lei | |
| 138 | 861345-00 | 1 | END CAP | 70,39 Lei | |
| 139 | 861336-02 | 1 | CAP D.50+BUSHING | 30,87 Lei | |
| 140 | 863015-00 | 1 | MOTOR TIE ROD-DW320 | 4,57 Lei | |
| 142 | 868412-04 | 1 | STATOR SA 230V | 1158,31 Lei | |
| 143 | 860080-02 | 1 | RING,AXIAL LOAD 34.5X28X0.5 | 4,57 Lei | |
| 145 | 861349-00 | 1 | CIRCLIP | 4,57 Lei | |
| 146 | 861338-00 | 1 | SPRING | 4,57 Lei | |
| 147 | 949894-12 | 2 | SCREW | 4,57 Lei | |
| 149 | 868768-07 | 1 | BEARING 6202 | 34,05 Lei | |
| 150 | 861721-12 | 1 | BEARING 6203 2RS ISB | 17,02 Lei | |
| 152 | 947614-00 | 1 | RING D.100 | 12,71 Lei | |
| 154 | N058265 | 1 | AUXILIARY GUARD DW711 | 57,81 Lei | |
| 155 | 860083-04 | 2 | NUT,HEX THICK M.8 UNI 5587 | 4,57 Lei | |
| 156 | 760298-01 | 3 | PAD, WEAR | 4,57 Lei | |
| 157 | 860610-01 | 1 | PUSH STICK | 30,87 Lei | |
| 159 | 861923-00 | 1 | RIP GRADUATED SCALE DW711 | 15,12 Lei | |
| 160 | 941535-00 | 1 | SQ NUT M8 DIN557 | 4,57 Lei | |
| 161 | 860084-03 | 1 | SCREW,PAN.PHAB 4.2X9.5UNI6954 | 4,57 Lei | |
| 162 | 123106-00 | 1 | STRAP,CABLE 1/4 H NYLON | 4,57 Lei | |
| 166 | 949702-42 | 1 | SCREW HEX.HD 6X60 UNI5737 | 4,57 Lei | |
| 168 | 861257-00 | 1 | CLAMP E25 | 5,21 Lei | |
| 170 | 330045-49 | 7 | SCREW | 4,57 Lei | |
| 175 | 946862-01 | 1 | SCALE | 13,85 Lei | |
| 181 | 868743-03 | 1 | S/A SLIDING FENCE DW711 | 80,04 Lei | |
| 187 | 860083-13 | 2 | NUT,HEX THIN M.6 UNI5589 ZINC | 4,57 Lei | |
| 191 | 868708-00 | 1 | BALL 6,3 mm | 4,57 Lei | |
| 192 | 861978-00 | 1 | FENCE | 96,56 Lei | |
| 193 | 860073-08 | 2 | WASHER | 4,57 Lei | |
| 194 | 931997-00 | 1 | SCREW | 4,57 Lei | |
| 196 | 949743-02 | 2 | SCREW | 4,57 Lei | |
| 816 | 325559-00 | 1 | AUFKL,PROD. DEWALT | 5,21 Lei | |
| 817 | N058264 | 1 | LABEL WARNING DW711 T.6 | 12,71 Lei | |
| 821 | N050416 | 1 | NAMEPLATE DW711-QS T.6 | 13,5 Lei | |
| 838 | 559570-99 | 1 | SERVICE TOOL | 241,14 Lei | |
| 847 | 868411-01 | 1 | ROTOR DW711+SPRING+RING 8618 | 667,9 Lei |
