DEWALT SCREWDRIVER (Type 5)
SKU Produs: DW268K /Type: 5
| Pozitie | Cod piesa | Piese utilizate | Nume piesa | Pret | Cantitate/Adauga in cos |
|---|---|---|---|---|---|
| 1 | 579598-13 | 1 | SA ARMATURE AND BEARING 240 SERVICE ) | 264,01 Lei | |
| 2 | N803540 | 1 | FIELD SA | 181,55 Lei | |
| 5 | 401877-01 | 1 | SA BRUSH HOLDER | 17,02 Lei | |
| 6 | 401878-01 | 1 | SA BRUSH HOLDER | 17,4 Lei | |
| 7 | N023114 | 1 | SA SWITCH 230V (SERVICE) | 157,92 Lei | |
| 8 | 330120-86 | 1 | CORD, PWR SPLY EURO | 70,39 Lei | |
| 10 | 605040-06 | 1 | BEARING,BALL | 13,85 Lei | |
| 13 | N014399 | 1 | FIELD CASE (MOULD) | 88,55 Lei | |
| 14 | 1006771-00 | 1 | SA COVER HANDLE - 2ND STAGE (MOULD) | 70,39 Lei | |
| 15 | 402648-00 | 1 | CORD CLAMP | 4,57 Lei | |
| 16 | N918736 | 1 | CORD PROTECTOR | 5,21 Lei | |
| 17 | 330019-13 | 3 | SCREW,PLSTC THD FORM M4X19 T20 | 4,57 Lei | |
| 18 | 330065-06 | 2 | SCREW PLSTC THD FROM M4X12 T20 | 4,57 Lei | |
| 19 | 389824-00 | 1 | RUBBER BOOT | 4,57 Lei | |
| 20 | 176811-00 | 1 | FAN BAFFLE | 7,37 Lei | |
| 21 | 949638-02 | 3 | SMALL RUBBER | 4,57 Lei | |
| 22 | 395047-00 | 1 | LABEL, IDENTITY DEWALT 34*48 | 4,57 Lei | |
| 24 | 176706-00SV | 1 | GEARCASE | 80,04 Lei | |
| 26 | 605040-20 | 1 | Ball Brg | 17,02 Lei | |
| 27 | 176708-00SV | 1 | SPINDLE AND GEAR | 145,09 Lei | |
| 28 | 388761-00 | 1 | COVER, GEARCASE | 21,85 Lei | |
| 29 | 23813-00 | 1 | WASHER | 5,1 Lei | |
| 30 | 450556-00 | 1 | SA NOSEPIECE | 384 Lei | |
| 30 | NA128417 | 1 | NOSE SA | 472,24 Lei | |
| 32 | 021287-00 | 1 | GUIDE | 4,57 Lei | |
| 32 | 23824200 | 1 | HANDLE | 24,9 Lei | |
| 32 | 25121501 | 1 | BRUSH | 30,1 Lei | |
| 32 | 25351500 | 1 | KEY 34X36 | 40,9 Lei | |
| 32 | 25922908 | 1 | NUT | 8,4 Lei | |
| 33 | 090866-00 | 1 | WASHER | 25,54 Lei | |
| 34 | 086134-00 | 1 | SPRING, COMPRESSION | 4,57 Lei | |
| 35 | 450360-00 | 1 | SPINDLE | 96,56 Lei | |
| 36 | 099047-01 | 1 | BALL | 4,7 Lei | |
| 36 | 99047-01 | 1 | BALL | 4,5 Lei | |
| 37 | 090639-02 | 1 | COLLAR | 52,22 Lei | |
| 38 | 387451-00 | 1 | RETAINER | 37,73 Lei | |
| 39 | 450555-00 | 1 | ADJUSTABLE STOP | 52,22 Lei | |
| 40 | 090596-00 | 1 | SEAL | 21,85 Lei | |
| 41 | 087928-00 | 1 | SPRING | 5,3 Lei | |
| 41 | 87928-00 | 1 | SPRING | 5,1 Lei | |
| 42 | 21360-00 | 1 | RETAINER | 4,57 Lei | |
| 45 | 330019-14 | 1 | SCREW, PLASTIC THREAD FORM M4X25 T20 | 4,57 Lei | |
| 46 | 176655-00 | 1 | GASKET | 4,57 Lei | |
| 47 | 000903-00 | 8 | BALL | 37,73 Lei | |
| 48 | 087692-00 | 1 | RING, RETAINING, INTERNAL | 4,57 Lei | |
| 48 | 176689-00 | 1 | RETAINER, BEARING | 4,57 Lei | |
| 49 | 093105-01 | 1 | HOUSING, CLUTCH | 219,9 Lei | |
| 50 | 910560 | 2 | BEARING, NEEDLE 6 * 10 * 9 | 8,64 Lei | |
| 54 | 93129-00 | 1 | BEARING DW226 | 8,4 Lei | |
| 55 | 176731-00SV | 1 | SPINDLE AND GEAR | 169,36 Lei | |
| 56 | 176732-00 | 3 | WASHER, THRUST | 4,57 Lei | |
| 57 | 143079-00 | 1 | BEARING, THRUST | 5,21 Lei | |
| 58 | 330019-16 | 2 | SCREW, PLASTIC THD FORM, M4*38 T20 | 4,57 Lei | |
| 59 | 089210-00 | 2 | RING, RETAINER, ROUND | 6,23 Lei | |
| 60 | N737331 | 1 | CLUTCH | 34,05 Lei | |
| 61 | 320842-19 | 1 | CAPACITOR, 0.22uF | 7,37 Lei | |
| 65 | 86211-00 | 1 | SPRING | 4,5 Lei | |
| 68 | 390198-00 | 2 | SCREW | 4,57 Lei | |
| 177 | N023113 | 1 | BRUSH PAIR 230V SA | 57,81 Lei | |
| 800 | 870889-02 | 1 | RENOLIT PARAGON EP 1/2 | 52,22 Lei | |
| 801 | 69542-00 | 1 | GREASE | 730,3 Lei | |
| 821 | N424910 | 1 | LABEL RATING DW268-QS05 | 4,7 Lei |
