DEWALT RADIAL ARM SAW (Type 1)
SKU Produs: DW1501----J /Type: 1
| Pozitie | Cod piesa | Piese utilizate | Nume piesa | Pret | Cantitate/Adauga in cos |
|---|---|---|---|---|---|
| 1 | 930076-00 | 4 | SELF TAPPING SCREW 4,2X16 | 4,7 Lei | |
| 2 | 868649-00 | 1 | KIT HANDLE DW720 | 133,4 Lei | |
| 2 | 949701-12 | 2 | RD.HD.SCREW M.5X25 | 4,7 Lei | |
| 3 | 860089-39 | 2 | SCREW,FIL.HD M5X60 UNI 6107 | 4,7 Lei | |
| 4 | 860085-20 | 1 | SCREW,HEX M.8X30 UNI 5739 | 4,7 Lei | |
| 5 | 860073-03 | 1 | WASHER,FLAT 8.4X17 UNI6592 ZN | 4,7 Lei | |
| 6 | 860083-02 | 2 | NUT,HEX THICK M.5 UNI 5587 | 4,7 Lei | |
| 8 | 860083-02 | 2 | NUT,HEX THICK M.5 UNI 5587 | 4,7 Lei | |
| 9 | 944654-00 | 1 | CLAMP,CABLE(NUT)G.3/8 HOLE 12 | 8,8 Lei | |
| 10 | 944590-00 | 1 | BUSHING,CABLE D.10XD.14X5 | 5,3 Lei | |
| 11 | 861385-04 | 1 | WEBER SWITCH | 483,2 Lei | |
| 13 | 860083-03 | 1 | NUT,HEX THICK M.6 UNI 5587 | 4,7 Lei | |
| 16 | 720959-00 | 1 | WASHER,FLAT 6.4X12.5 UNI 6592 | 4,7 Lei | |
| 18 | 860083-04 | 1 | NUT,HEX THICK M.8 UNI 5587 | 4,7 Lei | |
| 22 | 944590-00 | 1 | BUSHING,CABLE D.10XD.14X5 | 5,3 Lei |
