DEWALT RANDOM ORBITAL SANDER (Type 10)
SKU Produs: DCW200 /Type: 10
| Pozitie | Cod piesa | Piese utilizate | Nume piesa | Pret | Cantitate/Adauga in cos |
|---|---|---|---|---|---|
| 1 | N697716 | 1 | CLAMSHELL SET | 41,93 Lei | |
| 2 | N603948 | 1 | HOUSING TOP | 25,54 Lei | |
| 3 | NA039901 | 1 | MOTOR SWITCH SA | 613,14 Lei | |
| 4 | N689070 | 1 | FAN | 30,87 Lei | |
| 5 | N416160 | 1 | SEAL | 4,57 Lei | |
| 6 | N596411 | 1 | BAFFLE FAN | 13,85 Lei | |
| 7 | 330019-02 | 2 | SCREW, PLSTC THD FORM M3.5X13 T15 | 4,57 Lei | |
| 8 | NA146881 | 1 | PLATEN | 52,22 Lei | |
| 9 | N360702 | 1 | COUNTERWEIGHT | 6,23 Lei | |
| 10 | N345099 | 1 | WASHER | 4,57 Lei | |
| 11 | 098012-11 | 1 | SCREW, MACHINE | 4,57 Lei | |
| 12 | N472412 | 4 | LEG | 19,95 Lei | |
| 13 | N402677 | 1 | END CAP | 7,37 Lei | |
| 13 | N402805 | 1 | MOTOR HOUSING CL ALLIGATOR | 78,1 Lei | |
| 14 | N492998 | 1 | PAD SA | 106,98 Lei | |
| 15 | 330019-12 | 11 | SCREW | 4,57 Lei | |
| 16 | 330019-03 | 4 | Screw M3.5X16 T15 | 4,57 Lei | |
| 17 | N453948 | 1 | SPRING | 25,54 Lei | |
| 18 | N728006 | 1 | BUMPER | 4,57 Lei | |
| 19 | N728008 | 1 | BUMPER | 4,57 Lei | |
| 20 | N581601 | 1 | SPEED REGULATOR | 41,93 Lei | |
| 21 | N129171 | 1 | O RING | 4,57 Lei | |
| 22 | N637726 | 1 | DUST PORT | 17,02 Lei | |
| 23 | N273733 | 1 | DUST BAG SA | 30,87 Lei | |
| 24 | 144954-00 | 1 | PUNCH, PAPER | 10,29 Lei | |
| 27 | N747818 | 1 | MODULE | 130,35 Lei | |
| 30 | 330003-64 | 1 | BEARING, BALL | 30,87 Lei | |
| 31 | N464703 | 1 | CLAMP | 19,95 Lei | |
| 32 | N360481 | 1 | SPRING | 6,23 Lei | |
| 33 | N396569 | 1 | PIN | 7,37 Lei | |
| 34 | N366359 | 1 | CLAMP | 13,85 Lei | |
| 35 | N369879 | 2 | CLIP | 4,57 Lei | |
| 36 | N372479 | 1 | SEAL | 13,85 Lei | |
| 37 | N684701 | 1 | DUST PORT | 13,85 Lei |
