DEWALT ANGLE GRINDER (Type 2)
SKU Produs: DCG200NT /Type: 2
| Pozitie | Cod piesa | Piese utilizate | Nume piesa | Pret | Cantitate/Adauga in cos |
|---|---|---|---|---|---|
| 1 | N645520 | 1 | CLAMSHELL SET | 127,2 Lei | |
| 1 | N921148 | 1 | CLAMSHELL SET | 88,55 Lei | |
| 2 | N508013 | 1 | GEARCASE SA | 88,55 Lei | |
| 3 | 391969-00 | 1 | WASHER, INNER CLAMP M14 | 8,64 Lei | |
| 4 | N484250 | 1 | OUTER FLANGE | 57,81 Lei | |
| 5 | N661081 | 1 | MOTOR & SWITCH SA | 1087,42 Lei | |
| 6 | N455880 | 1 | ARMATURE | 225,26 Lei | |
| 7 | N503373 | 1 | GEARCASE COVER SA | 34,05 Lei | |
| 8 | N372039 | 1 | NUT M7 | 4,57 Lei | |
| 9 | N071836 | 1 | ROLL PIN 2.5 X 10.9 | 4,57 Lei | |
| 10 | N412210 | 4 | SCREW | 4,57 Lei | |
| 11 | N575500 | 2 | SCREW | 4,57 Lei | |
| 13 | N436965 | 2 | VENT | 17,02 Lei | |
| 14 | 330045-06 | 3 | SCREW, METAL THD FRM,M4X16 T20 | 4,57 Lei | |
| 15 | 330045-08 | 3 | SCREW | 4,57 Lei | |
| 16 | 330015-00 | 2 | NUT | 4,57 Lei | |
| 17 | N122099 | 1 | BLOCK | 4,57 Lei | |
| 20 | 90611830 | 16 | SCREW | 4,57 Lei | |
| 21 | N467560 | 1 | STRIKE PLATE | 4,57 Lei | |
| 22 | N449470 | 1 | Gear | 130,35 Lei | |
| 23 | 444793-00 | 1 | RETAINING RING | 4,57 Lei | |
| 24 | N307625 | 1 | O RING 1.5X40 | 4,57 Lei | |
| 25 | N481950 | 1 | RETAINER RING | 4,57 Lei | |
| 26 | N390307 | 1 | SPACER | 10,29 Lei | |
| 27 | 605040-24 | 1 | BEARING | 13,85 Lei | |
| 28 | N390308 | 1 | WASHER SPRING | 6,23 Lei | |
| 29 | N448927 | 1 | WASHER | 17,02 Lei | |
| 30 | N566404 | 1 | SPINDLE | 52,22 Lei | |
| 31 | N263699 | 1 | THOR SPINDLE LOCK O-RING | 4,57 Lei | |
| 32 | N278899 | 1 | SPINDLE LOCK BUTTON | 4,57 Lei | |
| 33 | N263579 | 1 | THOR SPINDLE LOCK SPRING | 4,57 Lei | |
| 34 | N481683 | 1 | LOCK PIN | 7,37 Lei | |
| 35 | N119639 | 1 | O RING ,RUBBER | 4,57 Lei | |
| 36 | N461411 | 1 | PINION | 25,54 Lei | |
| 37 | N175104 | 1 | BEARING BALL | 13,85 Lei | |
| 38 | N453031 | 1 | RET RING w FINGERS | 4,57 Lei | |
| 39 | N401958 | 1 | DEFLECTOR | 5,21 Lei | |
| 40 | N456830 | 1 | BRAND LABEL | 4,57 Lei | |
| 41 | N456232 | 1 | LABEL | 4,57 Lei | |
| 42 | N626791 | 1 | RATING PLATE | 4,57 Lei | |
| 43 | N456831 | 1 | BRAND LABEL | 4,57 Lei | |
| 44 | N456832 | 1 | BRAND LABEL | 4,57 Lei | |
| 45 | N456231 | 1 | LABEL | 4,57 Lei | |
| 46 | N107295 | 1 | HEX KEY 6 MM | 6,23 Lei | |
| 47 | N461735 | 1 | TERMINAL BLOCK SPRING | 4,57 Lei | |
| 49 | N655436 | 1 | MODULE | 120,82 Lei | |
| 50 | N594092 | 1 | BASE PLATE | 145,09 Lei | |
| 51 | N594068 | 1 | HOUSING | 106,98 Lei | |
| 52 | N594075 | 1 | COVER HOUSING | 96,56 Lei | |
| 53 | N704921 | 1 | LEVER RELEASE | 34,05 Lei | |
| 54 | N567567 | 1 | KNOB | 10,29 Lei | |
| 55 | N567569 | 1 | ADJUSTER DEPTH | 8,64 Lei | |
| 56 | N568321 | 1 | HOUSING HANDLE | 25,54 Lei | |
| 57 | N568427 | 1 | HOUSING HANDLE | 30,87 Lei | |
| 58 | N626842 | 4 | CLIP | 4,57 Lei | |
| 59 | N579929 | 4 | WHEEL | 4,57 Lei | |
| 60 | N612334 | 1 | DUST PORT | 20,4 Lei | |
| 61 | N573502 | 1 | HANDLE COVER | 25,54 Lei | |
| 62 | N645872 | 1 | BUTTON RELEASE | 6,23 Lei | |
| 63 | N652848 | 1 | LATCH | 4,57 Lei | |
| 64 | N625384 | 1 | LATCH | 21,85 Lei | |
| 65 | N566405 | 1 | SPRING | 6,23 Lei | |
| 66 | N571261 | 1 | SPRING | 4,57 Lei | |
| 67 | N612591 | 1 | SPRING | 4,57 Lei | |
| 68 | N589180 | 1 | SPRING | 4,57 Lei | |
| 69 | N566406 | 1 | SPACER | 30,87 Lei | |
| 70 | N566636 | 1 | SPACER | 37,73 Lei | |
| 71 | N566637 | 1 | SPACER | 34,05 Lei | |
| 72 | N570527 | 1 | SPACER | 57,81 Lei | |
| 73 | N593727 | 1 | SCREW | 4,57 Lei | |
| 74 | N596355 | 1 | SCREW | 7,37 Lei | |
| 75 | N606388 | 1 | SCREW | 7,37 Lei | |
| 76 | 607395-00 | 1 | SCREW | 5,21 Lei | |
| 77 | N620974 | 1 | NUT | 7,37 Lei | |
| 78 | N629987 | 2 | O RING | 4,57 Lei | |
| 79 | N467767 | 1 | NUT HEX M6 LH | 4,57 Lei | |
| 80 | N687277 | 2 | RUBBER | 4,57 Lei | |
| 81 | N697836 | 1 | COVER | 13,85 Lei | |
| 82 | N684843 | 1 | SCREW | 4,57 Lei | |
| 83 | N570093 | 1 | BAR | 70,39 Lei | |
| 84 | N644184 | 1 | LABEL | 5,21 Lei | |
| 85 | N644187 | 1 | LABEL | 4,57 Lei | |
| 86 | 330045-69 | 4 | SCREW | 10,29 Lei | |
| 87 | N641115 | 1 | INSERT | 12,71 Lei | |
| 88 | N696816 | 1 | INSERT | 8,64 Lei | |
| 89 | N772393 | 1 | SHOE SA | 375,31 Lei | |
| 90 | N787996 | 1 | INSERT | 4,57 Lei | |
| 91 | N831593 | 2 | SCREW | 4,57 Lei | |
| 800 | 583534-00 | 1 | RHEOLUBE 380-G1 | 1087,42 Lei | |
| 860 | H1400196008 | 1 | HANDLE | 24,9 Lei | |
| 860 | H1400198008 | 1 | HANDLE | 17,02 Lei | |
| 861 | N429655 | 1 | KITBOX | 240,38 Lei | |
| 862 | N409477 | 1 | LATCH | 8,64 Lei | |
| 863 | P910190 | 2 | LATCH (Better Latch - C) | 13,85 Lei | |
| 864 | N644738 | 1 | INSERT | 57,81 Lei | |
| 865 | N666467 | 1 | INSERT | 15,12 Lei |
