DEWALT CORDLESS CIRCULAR SAW Type 1
SKU Produs: DC390N
| Pozitie | Cod piesa | Piese utilizate | Nume piesa | Pret | Cantitate/Adauga in cos |
|---|---|---|---|---|---|
| 4 | 330019-04 | 8 | SCREW, PLASTIC THREAD FORM M3.5 X 19 T1 | 4,57 Lei | |
| 5 | 398987-00 | 4 | SCREW | 4,57 Lei | |
| 7 | 098000-11 | 1 | HEX KEY 5mm | 5,21 Lei | |
| 9 | 605107-00 | 1 | BUTTON LOCK-OFF | 20,4 Lei | |
| 10 | 330019-40 | 1 | SCREW DW007K | 4,57 Lei | |
| 11 | 389120-00 | 1 | SPRING DW007K | 4,57 Lei | |
| 12 | 388531-00 | 1 | PIN DW007K | 5,21 Lei | |
| 13 | 620354-00 | 1 | TERMINAL | 33,2 Lei | |
| 15 | 605081-01 | 1 | GASKET | 5,21 Lei | |
| 16 | 613783-00 | 8 | SCREW | 4,57 Lei | |
| 17 | 605094-00 | 1 | WIPER, RUBBER | 4,57 Lei | |
| 18 | 629444-00 | 1 | SPINDLE LOCK | 7,37 Lei | |
| 22 | 384127-01 | 3 | SCREW, MACHINE PAN HD | 4,57 Lei | |
| 26 | 330021-01 | 1 | NUT, 6KT M6 ISO7040 | 17,02 Lei | |
| 29 | 610134-00 | 1 | SCREW | 4,57 Lei | |
| 30 | 614048-00 | 1 | SPIRAL PIN | 4,57 Lei | |
| 33 | 330045-45 | 9 | SCREW TAPTITE M4x12, SLT/T20 | 4,57 Lei | |
| 35 | 150383-00 | 1 | RETAINER | 5,21 Lei | |
| 37 | 605105-00 | 1 | LEVER | 7,37 Lei | |
| 38 | 618901-00 | 1 | SHAFT | 19,95 Lei | |
| 39 | 330045-14 | 1 | SCREW M5X16 T25 | 4,57 Lei | |
| 40 | 142013-00 | 1 | SPACER | 4,57 Lei | |
| 41 | 098128-85 | 1 | CARRIAGE BOLT | 4,57 Lei | |
| 42 | 395889-00 | 1 | SA KNOB | 4,57 Lei | |
| 43 | N022876 | 1 | CARRIAGE BOLT | 4,57 Lei | |
| 44 | 381069-00 | 1 | SCREW DW007K | 4,57 Lei | |
| 45 | 058287-00 | 1 | SPRING, CPRSN | 4,57 Lei | |
| 46 | 396992-02 | 1 | KNOB | 4,57 Lei | |
| 47 | 610046-00 | 1 | WASHER INNER CLAMP | 15,12 Lei | |
| 48 | N621119 | 1 | WASHER, CLAMP OUTER | 15,12 Lei | |
| 54 | 391032-00 | 1 | SA BEARING AND BOOT | 21,85 Lei | |
| 55 | 610124-01 | 1 | BAFFLE | 17,02 Lei | |
| 56 | 610126-00 | 2 | BRUSH SA | 19,95 Lei | |
| 57 | 330019-25 | 2 | SCREW, PLASTIC THD FORM, M3.5X65 T15 | 4,7 Lei | |
| 856 | 381091-01 | 1 | FENCE DW936 | 17,02 Lei | |
| 867 | 645221-00 | 2 | CAP | 4,57 Lei | |
| 867 | 650912-00 | 1 | SAFETY CAP (Li-Ion - Nano) | 4,5 Lei |
