BLACK+DECKER FAN - STAND (Type 1)
SKU Produs: BXAC9000E /Type: 1
| Pozitie | Cod piesa | Piese utilizate | Nume piesa | Pret | Cantitate/Adauga in cos |
|---|---|---|---|---|---|
| 1 | 1004780-29 | 1 | COVER | 240,38 Lei | |
| 2 | 1004780-30 | 1 | WINDOW | 13,85 Lei | |
| 3 | 1004780-31 | 1 | PANEL | 96,56 Lei | |
| 4 | 1004780-32 | 1 | PLATE | 145,09 Lei | |
| 5 | 1004780-33 | 1 | CONDENSOR | 318,26 Lei | |
| 6 | 1004780-34 | 1 | FILTER | 52,22 Lei | |
| 7 | 1004780-35 | 1 | DUCT | 145,09 Lei | |
| 8 | 1004780-36 | 1 | FILTER | 41,93 Lei | |
| 9 | 1004780-37 | 1 | BLADE | 213,19 Lei | |
| 10 | 1004780-38 | 1 | HOUSING | 145,09 Lei | |
| 11 | 1004780-39 | 1 | COVER | 145,09 Lei | |
| 12 | 1004780-40 | 1 | MOTOR | 225,26 Lei | |
| 13 | 1004780-41 | 1 | ROTOR | 213,19 Lei | |
| 14 | 1004780-42 | 1 | SUPPORT | 37,73 Lei | |
| 15 | 1004780-43 | 1 | COVER | 145,09 Lei | |
| 16 | 1004780-44 | 1 | SUPPORT | 13,85 Lei | |
| 17 | 1004780-45 | 1 | MOTOR SA | 80,04 Lei | |
| 18 | 1004780-46 | 1 | COVER | 70,39 Lei | |
| 19 | 1004780-47 | 1 | DISPLAY | 276,84 Lei | |
| 20 | 1004780-48 | 1 | ROD | 17,02 Lei | |
| 21 | 1004780-49 | 1 | CONTROL PANEL | 30,87 Lei | |
| 22 | 1004780-50 | 1 | JOINT | 17,02 Lei | |
| 23 | 1004780-51 | 1 | ROD | 17,02 Lei | |
| 24 | 1004780-52 | 1 | BLADE | 17,02 Lei | |
| 25 | 1004780-53 | 1 | COVER | 80,04 Lei | |
| 26 | 1004780-54 | 1 | FLANGE | 37,73 Lei | |
| 27 | 1004780-55 | 1 | AFTER COOLER | 318,26 Lei | |
| 28 | 1004780-56 | 1 | FILTER | 70,39 Lei | |
| 29 | 1004780-57 | 1 | BODY | 240,38 Lei | |
| 30 | 1004780-58 | 1 | FILTER | 70,39 Lei | |
| 31 | 1004780-59 | 1 | CLAMP | 7,37 Lei | |
| 32 | 1004780-60 | 1 | HOOK | 10,29 Lei | |
| 33 | 1004780-61 | 1 | GRILLE | 19,95 Lei | |
| 34 | 1004780-62 | 1 | FLANGE | 8,64 Lei | |
| 35 | 1004780-63 | 1 | CAPACITOR | 80,04 Lei | |
| 36 | 1004780-64 | 1 | BRACKET | 10,29 Lei | |
| 37 | 1004780-65 | 1 | PANEL | 145,09 Lei | |
| 38 | 1004780-66 | 1 | COVER | 13,85 Lei | |
| 39 | 1004780-67 | 1 | PCB | 375,31 Lei | |
| 40 | 1004780-68 | 1 | BOX | 25,54 Lei | |
| 41 | 1004780-69 | 1 | MICRO SWITCH | 52,22 Lei | |
| 42 | 1004780-70 | 1 | FLOAT | 19,95 Lei | |
| 43 | 1004780-71 | 1 | BRACKET | 13,85 Lei | |
| 44 | 1004780-72 | 1 | WHEEL | 12,71 Lei | |
| 45 | 1004780-73 | 1 | CONDENSOR | 980,83 Lei | |
| 46 | 1004780-74 | 1 | BASE | 225,26 Lei | |
| 47 | 1004780-75 | 1 | SCREW | 19,95 Lei | |
| 48 | 1004780-76 | 1 | WASHER | 7,37 Lei | |
| 49 | 1004780-77 | 1 | NUT | 7,37 Lei | |
| 50 | 1004780-78 | 1 | MOTOR SA | 6,23 Lei | |
| 51 | 1004780-79 | 1 | SUPPORT | 25,54 Lei | |
| 52 | 1004780-80 | 1 | FAN SA | 25,54 Lei | |
| 53 | 1004780-81 | 1 | VALVE | 240,38 Lei | |
| 54 | 1004780-82 | 1 | GASKET | 8,64 Lei | |
| 55 | 1004780-83 | 1 | PLUG | 13,85 Lei | |
| 56 | 1004780-84 | 1 | BUTTON | 25,54 Lei | |
| 57 | 1004780-85 | 1 | CONNECTOR | 8,64 Lei | |
| 58 | 1004780-86 | 1 | MOTOR SA | 225,26 Lei | |
| 59 | 1004780-87 | 1 | GRILLE | 19,95 Lei | |
| 60 | 1004780-88 | 1 | CONNECTOR | 145,09 Lei | |
| 61 | 1004780-89 | 1 | REMOTE CONTROL | 349,13 Lei | |
| 62 | 1004780-90 | 1 | HOSE | 169,36 Lei | |
| 63 | 1004780-91 | 1 | ADAPTOR | 120,82 Lei | |
| 64 | 1004780-92 | 1 | ADAPTOR | 106,98 Lei | |
| 65 | 1004780-93 | 1 | CORDSET | 41,93 Lei |
