DEWALT MASINA DE TUNS GARD VIU CU ACUMULATOR (Type 1)
SKU Produs: DCMPH622N /Type: 1
| Pozitie | Cod piesa | Piese utilizate | Nume piesa | Pret | Cantitate/Adauga in cos |
|---|---|---|---|---|---|
| 1 | NB142575 | 1 | HOUSING REAR | 73,19 Lei | |
| 2 | NB142576 | 1 | HANDLE SA | 43,16 Lei | |
| 3 | NA645017 | 1 | BAFFLE SA | 31,19 Lei | |
| 4 | NB406029 | 1 | MOTOR SA | 373,38 Lei | |
| 5 | NA720473 | 1 | MOUNTING BRACKET | 58,17 Lei | |
| 6 | 609932-01 | 3 | SCREW | 4,57 Lei | |
| 7 | 330019-00 | 5 | SCREW, PLASTIC THREAD FORM M3 * 16 T10 | 4,57 Lei | |
| 9 | 650974-00 | 1 | WIRE NUT HIGH TECH | 5,21 Lei | |
| 11 | NA710204 | 1 | END CAP | 18,06 Lei | |
| 12 | N787996 | 1 | INSERT | 4,57 Lei | |
| 13 | N831593 | 2 | SCREW | 4,57 Lei | |
| 14 | NA1014627 | 1 | SWITCH | 31,19 Lei | |
| 15 | NA607677 | 1 | TRIGGER | 16,49 Lei | |
| 16 | NA355514 | 1 | SPRING | 3,78 Lei | |
| 17 | 90608942 | 1 | PIN | 4,57 Lei | |
| 18 | NA296124 | 1 | MODULE | 161,18 Lei | |
| 19 | N261987 | 1 | CAP | 4,57 Lei | |
| 22 | 90636612 | 1 | RETAINER | 7,37 Lei | |
| 23 | 90628376 | 1 | SCREW | 4,57 Lei | |
| 32 | N595379 | 4 | M5X8 Socket Head Cap Screw | 4,57 Lei | |
| 33 | N813134 | 3 | WASHER SPRING | 4,57 Lei | |
| 34 | 569639-00 | 8 | WASHER | 4,57 Lei | |
| 36 | 330019-12 | 22 | SCREW | 4,57 Lei | |
| 37 | 330024-54 | 1 | MACHINE SCREW M3 X 0.5 | 4,57 Lei | |
| 44 | 330045-16 | 1 | Screw Metal | 4,57 Lei | |
| 48 | 90621610 | 1 | PLUG | 4,57 Lei | |
| 49 | 90640963 | 1 | PIN | 12,71 Lei | |
| 50 | N168103 | 2 | BALL BEARING 608 | 12,71 Lei | |
| 59 | 330045-45 | 1 | SCREW TAPTITE M4x12, SLT/T20 | 4,57 Lei | |
| 61 | 395441-00 | 2 | SCREW | 4,7 Lei | |
| 67 | N502343 | 1 | STRAP | 34,05 Lei | |
| 71 | 593216-00 | 1 | SCREW | 4,57 Lei | |
| 72 | NA723504 | 1 | HANDLE SA | 66,15 Lei | |
| 800 | 583534-00 | 1 | RHEOLUBE 380-G1 | 1087,42 Lei |
