DEWALT MASINA DE PILIT ELECTRICA (Type 1)
SKU Produs: DCM200N /Type: 1
| Pozitie | Cod piesa | Piese utilizate | Nume piesa | Pret | Cantitate/Adauga in cos |
|---|---|---|---|---|---|
| 1 | 330019-00 | 12 | SCREW, PLASTIC THREAD FORM M3 * 16 T10 | 4,57 Lei | |
| 2 | NA120308 | 1 | LED | 25,52 Lei | |
| 3 | NA153477 | 1 | SPEED REGULATOR | 43,16 Lei | |
| 4 | NA205214 | 1 | HOUSING MOTOR | 21,11 Lei | |
| 5 | NA373986 | 1 | MOTOR & SWITCH SA | 471,87 Lei | |
| 6 | NA417434 | 1 | ROTOR SA | 161,18 Lei | |
| 7 | NA105798 | 1 | TERMINAL BLOCK | 15,12 Lei | |
| 8 | NA168576 | 1 | HOUSING SA | 43,16 Lei | |
| 9 | NA612330 | 1 | COVER | 5,15 Lei | |
| 10 | NA104040 | 1 | BUTTON LOCK-OFF | 18,06 Lei | |
| 11 | NA395380 | 1 | BRAKE ADAPTER | 107,73 Lei | |
| 12 | NA363158 | 3 | SCREW | 3,78 Lei | |
| 13 | NA103719 | 1 | BLOCK | 3,78 Lei | |
| 14 | NA205186 | 1 | BODY-BAND FILE BODY | 79,8 Lei | |
| 15 | NA114682 | 1 | SCREW | 6,09 Lei | |
| 16 | NA356205 | 1 | SCREW | 3,78 Lei | |
| 17 | NA205191 | 1 | LEVER LOCK | 21,11 Lei | |
| 18 | NA205257 | 1 | SLEEVE | 11,45 Lei | |
| 19 | NA089363 | 1 | COLLAR | 3,78 Lei | |
| 20 | NA205194 | 1 | WHEEL DRIVING | 28,14 Lei | |
| 21 | NA323171 | 1 | PLASTIC INSERT | 4,31 Lei | |
| 22 | N462739 | 2 | WASHER | 4,57 Lei | |
| 23 | NA377988 | 2 | SCREW | 3,78 Lei | |
| 24 | 640591-00 | 1 | WASHER PLAIN | 4,57 Lei | |
| 25 | NA089592 | 1 | CAM LEVER | 12,5 Lei | |
| 26 | NA103863 | 1 | SPRING | 3,78 Lei | |
| 27 | NA089588 | 1 | SCREW | 3,78 Lei | |
| 28 | NA089590 | 1 | COVER | 34,65 Lei | |
| 29 | NA089586 | 1 | PIN | 18,06 Lei | |
| 30 | NA322803 | 1 | FELT | 3,78 Lei | |
| 31 | NA107488 | 1 | SPRING | 3,78 Lei | |
| 32 | NA089589 | 1 | MAINSCREW SA-SA TRACKING SCREW | 11,45 Lei | |
| 33 | NA089595 | 1 | O RING | 3,78 Lei | |
| 34 | NA234451 | 1 | SPRING | 3,78 Lei | |
| 35 | NA395274 | 1 | ARM | 58,17 Lei | |
| 36 | NA395278 | 1 | ARM STROKE-SA CONTACT ARM, STRAIGHT, 1/2 | 99,86 Lei | |
| 37 | 330045-09 | 2 | SCREW, METAL THREAD FORM M4 X 30 T20 | 4,57 Lei | |
| 38 | N401305 | 1 | SIDE HANDLE | 19,95 Lei | |
| 201 | NA321907 | 1 | RATING LABEL | 3,78 Lei | |
| 202 | NA321909 | 1 | WARNING LABEL | 3,78 Lei | |
| 203 | NA321915 | 1 | LABEL | 3,78 Lei | |
| 204 | NA335891 | 1 | LABEL | 3,78 Lei | |
| 205 | NA392823 | 1 | LABEL | 3,78 Lei | |
| 301 | NA399461 | 1 | ARM | 79,8 Lei | |
| 302 | NA225323 | 1 | SHROUD | 6,09 Lei | |
| 830 | NA375089 | 1 | SERVICE TOOLING KIT | 34,65 Lei | |
| 3001 | NA399461 | 1 | ARM | 79,8 Lei | |
| 3002 | NA225323 | 1 | SHROUD | 6,09 Lei |
